| System |
2020 |
| Processor |
Intel Atom N270 1.6GHz |
| System Memory |
One 200 Pin 1.8V DDRII SODIMM Socket, total up to 2GB |
| Storage |
2.5" SATA HDD or CF |
| I/O |
Serial port *3 (RS232/422/485 *1, RS232*2) |
| USB 2.0*4 |
| Supports 4 In and 4 Out GPIO Port (Shared with 1x RS-232) |
| Ethernet, PCI-e Gbe LAN *2, RJ-45 |
| 1x DVI-I female connector for DVI-D and VGA Output |
| Audio, Line out *1, Phone Jack |
| Expansion Interface |
One Mini PCI Express Socket |
| OS Support |
Microsoft WinCE, XP Embedded, Win 7 |
| Power Requirement |
DC Jack, +12V~+24V Wide Range Input |
| Power Consumption |
20W |
| Mechanical |
| Construction |
Aluminum Alloy |
| Operation Temp. |
-2O°C ~ 60°C ambient w/ Air |
| Storage Temp. |
-40°C ~ 85°C |
| Relative Humidity |
10~95% @40°C, Non-condensing |
| Vibration |
5-17Hz, 0.1" double amplitude peak to peak, 1.5G acceleration peak to peak |
| Shock |
10G acceleration peak to peak (11ms) |
| Qualification |
Formal certification CE I FCC Class A |
| Mounting |
Wall Mount, VESA mount |
| Dimension |
182mm*136mm*35mm (L*W*H) |
| Weight(net) |
2.1lb (0.96kg) |
| Optional Order |
| Memory |
DDRII 1GB, DDRII 2GB |
| Storage |
2.5" SATA HDD 320GB, CF Card 4/8/16/32GB |
| OS |
Microsoft WinCE, XP Embedded, Win 7 |
| Wifi LAN |
RTL8188CUS-BC8-WB |
